华为AP3010DN-AGN刷FAT Cli配置wlan

有几个老旧的华为AP3010DN-AGN 瘦模式的，刷成胖模式也能用，本着废物利用原则，做了这个教程，3010DN-AGN FAT固件，官方不提供，在网上下载到一个R005的包，测试了一下可以正常使用，刷完之后显示AP3010DN （我的FIT版本也是这样显示的）不过没有关系，别外说明的是AGN 代表不同的传输技术，A:802.11a  G:802.11b/g  N:802.11n ，不会刷机看我之前的文章https://www.wmphp.com/6253.html

走过的坑：

1、因为AP3010DN-AGN机型太老，使用WEB配置模式 网页卡死，一天也配置不出来；

2、做一个脚本ap3010dn-agn-config.txt 放到TFTP服务器上，]tftp client-source -a 169.254.1.200 #设置AP本地IP  >tftp -i Vlanif1 169.254.1.20 get ap3010dn-agn-config.txt #下载配置，结果华为AP 没有载入配置的功能，只能动手敲；

3、由于固件太老，和新版本的命令发生很大变化。参考华为官方的命令，缺少密钥关键配置项，不完美，下面的代码经过测试无问题的。

ap-mode-switch prepare
ap-mode-switch check
ap-mode-switch tftp FatAP3X10XN_V200R005C10SPCa00.bin 169.254.1.20

固件包微信登录下载

# 进入系统视图

system-view
# 进入WLAN视图

wlan
# 创建安全配置文件并配置wpa-wpa2-PSK加密及密码

security-profile name sanjiang

security-policy wpa-wpa2

wpa-wpa2 authentication-method psk pass-phrase cipher 11223344 encryption-method tkip

quit
# 创建 WMM 配置文件

[Huawei-wlan] wmm-profile name wmm

# 可选：配置 WMM 参数

[Huawei-wlan-wmm-prof-wmm] quit
# 创建流量配置文件

traffic-profile name sanjiang

quit
# 配置2.4G射频模板

radio-profile name sanjiang-2g

wmm-profile name wmm

quit
# 配置5G射频模板

radio-profile name sanjiang-5g

wmm-profile name wmm

quit

quit
# 创建2.4G和5G共用的WLAN-BSS接口

interface wlan-bss 1

quit
interface wlan-bss 2

quit
wlan

# 创建服务集 for 2.4G

service-set name sanjiang-2g

ssid sanjiang

wlan-bss 1

security-profile name sanjiang

traffic-profile name sanjiang

quit
# 创建服务集 for 5G

service-set name sanjiang-5g

ssid sanjiang

wlan-bss 2

security-profile name sanjiang

traffic-profile name sanjiang

quit

quit
# 配置 2.4G 射频并绑定服务集

interface wlan-radio 0/0/0

radio-profile name sanjiang-2g

service-set name sanjiang-2g

quit
# 配置 5G 射频并绑定服务集

interface wlan-radio 0/0/1

radio-profile name sanjiang-5g

service-set name sanjiang-5g

quit

# 结束配置

quit

已把命令做成脚本，保存格式为.vbs即可，在SecureCRT 上执行脚本，全局替换SSID名（修改成自己的），我用的SecureCRT 6.5.0。

#$language = "VBScript"

#$interface = "1.0"
crt.Screen.Synchronous = True
' This automatically generated script may need to be

' edited in order to work correctly.
Sub Main

crt.Screen.Send "wlan" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "security-profile name sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-sec-prof-sanjiang]"

crt.Screen.Send "security-policy wpa-wpa2" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-sec-prof-sanjiang]"

crt.Screen.Send "wpa-wpa2 authentication-method psk pass-phrase cipher 11223344 encryption-method tkip" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-sec-prof-sanjiang]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "wmm-profile name wmm" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-wmm-prof-wmm]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "traffic-profile name sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-traffic-prof-sanjiang]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "radio-profile name sanjiang-2g" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-radio-prof-sanjiang-2g]"

crt.Screen.Send "wmm-profile name wmm" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-radio-prof-sanjiang-2g]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "radio-profile name sanjiang-5g" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-radio-prof-sanjiang-5g]"

crt.Screen.Send "wmm-profile name wmm" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-radio-prof-sanjiang-5g]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei]"

crt.Screen.Send "interface wlan-bss 1" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Bss1]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei]"

crt.Screen.Send "interface wlan-bss 2" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Bss2]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei]"

crt.Screen.Send "wlan" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "service-set name sanjiang-2g" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-2g]"

crt.Screen.Send "ssid sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-2g]"

crt.Screen.Send "wlan-bss 1" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-2g]"

crt.Screen.Send "security-profile name sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-2g]"

crt.Screen.Send "traffic-profile name sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-2g]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "service-set name sanjiang-5g" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-5g]"

crt.Screen.Send "ssid sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-5g]"

crt.Screen.Send "wlan-bss 2" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-5g]"

crt.Screen.Send "security-profile name sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-5g]"

crt.Screen.Send "traffic-profile name sanjiang" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-service-set-sanjiang-5g]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei-wlan-view]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei]"

crt.Screen.Send "interface wlan-radio 0/0/0" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Radio0/0/0]"

crt.Screen.Send "radio-profile name sanjiang-2g" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Radio0/0/0]"

crt.Screen.Send "service-set name sanjiang-2g" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Radio0/0/0]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei]"

crt.Screen.Send "interface wlan-radio 0/0/1" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Radio0/0/1]"

crt.Screen.Send "radio-profile name sanjiang-5g" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Radio0/0/1]"

crt.Screen.Send "service-set name sanjiang-5g" & chr(13)

crt.Screen.WaitForString "[Huawei-Wlan-Radio0/0/1]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "[Huawei]"

crt.Screen.Send "qu" & chr(13)

crt.Screen.WaitForString "<Huawei>"

crt.Screen.Send "s" & chr(8)

End Sub
